Windows

Security Subsystem​

  • Runs in user mode
  • Logon process (winlogon, LogonUI)
  • Local security authority (LSA)
    • Checks User Accounts
    • Provides access token
    • Responsible for auditing
  • Security Account Manager (SAM)
    • Maintains user account database used by LSA
    • Encrypts/hashes passwords

Windows​

  • Predominantly uses Access Control Lists, and has done since Windows NT
  • Extends the usual read, write and execute with:
    • Take ownership
    • Change permissions
    • Delete
  • 32-bit access masks (cf. Unix 9-bit)
  • A higher degree of control, with the associated complexity increase!

Access Control Matrix​

Access rights are defined individually for each combination of subject and object

  • Quite an abstract concept, but would allow for very fine grained control
  • Not practical Treats more than just files, also; registry keys, active directory objects, groups Inheritance is implemented - files can inherit ACLs from parent directories

Local/Domain Principals​

  • LSA creates a local principals - principal = MACHINE\principal
  • Domain principals administered on DC by domain admins

Groups​

  • Collection of SIDs
  • Can itself be an SID
  • Can thus be nested
  • Are not nest-able on local machines
  • Managed by a domain controller within Active Directory

Objects​

Passive entities in access operations In windows:

  • Executive objects (process, threads, etc.)
  • Private objects (files, directories) Securable objects have a security descriptor
  • Built-in securable objects managed by the OS
  • Private objects managed by application software

Access Tokens​

  • Security credentials for a login session stored in access token
  • Identifies the user, the user's groups, and the user's privileges

Subjects​

  • Process and threads
  • New processes get a copy of the parent access token, possibly modified
  • Individual access tokens are immutable, and can live beyond policy changes (TOCTTOU issue)

User Account Control​

  • After vista, admin users do not use an administrative access token by default
  • Two tokens, one heavily restricted and used by default
  • Prompt allows a user to spawn a process with the other token

Domains​

  • Single sign-on for network resources
  • Centralised security administration
  • Domain Controller (DC)
    • Handles user accounts and access control
    • Trusted 3rd party for authentication
  • Multiple DCs allow for decentralisation

Interactive Logon​

  • Allows users to auth
  • Begins with the Secure Attention Sequence - Crtl + Alt + Delete
  • Logon process differs slightly for local and domain auth Logon Process contains:
  • Winlogon - process responsible for authenticating users
  • Graphical Identification and Authentication (GINA)
  • Local Security Authority (LSA)
  • An authentication package (NTLM and Kerberos)
  • Security Account Manager (SAM)
  • Since vista, Credential Providers are allowed
